Barco 4K60 Tri-Combo Output Card




The 4K Tri-combo output card (TCO) supports single cable 4K/UHD60p outputs via DisplayPort 1.2, HDMI 2.0 and 12G SDI. In addition, 4K/UHD 30p via 6G SDI is supported, as well as 4x 3G SDI, for both quad 4K/UHD or multiple HD SDI outputs.

The output card is also backward compatible to DisplayPort 1.1a and HDMI 1.4a. Each card supports up to 6x HD, 4X Dual Link, or 2x 4K/UHD.


  • DP1.2 supports HDCP 1.3. HDMI 2.0 supports HDCP 1.4 and HDCP 2.2
  • 1x 4K@60p, 2 High-Speed (dual link type) or 4 HD outputs per card
  • 12G SDI supports UHD@60p 4:2:2 10bit
    Quad SDI 4K/UHD and 2SI (2 sample interleave) 4K/UHD formats
  • DP 1.2 output supports up to UHD@60p 4:4:4 10bit
  • HDMI 2.0 output supports up to UHD@60p 4:4:4 8bit
